Machines

At Power Repair Service, we have the equipment and features needed to provide fast, high quality service for any industrial repair need.

  • Kingston HL-2000 (2), 2500 (3), 3000 (2), 4000 (3)

    • 18”-22” Swings x 78”-157” Lengths
    Kingston HL Lathes
  • Kingston HD

    Kingston HD (Models HD-2290,22120)

    • 22” Swing x 90”-120” Length

  • Sharp 60360x

    • 60” Swing x 360” Length
    Sharp 60 x 360 Lathe

  • Niles 40” Model FPW

    • Table Dia: 40”
    • Turn Dia: 43 MIN / 51 MAX
    • Max Turn Height: 35”

  • OM VTO-16B

    • Table Dia: 63”
    • Turn Dia: 78”
    • Max Turn Height: 59”
    • Max Workpiece Weight: 17,600 lbs

  • Comet MB1130A

    • 26” U-Axis w/ 8” Travel
    • Travels X,Y,Z,W: 54 x 50 x 21.5 x 45
    • Rotary Table LxW: 59 x 49
    • Tailstock
    Comet MB1130A HBM

  • Sharp KMA-3 & VBM 5VL

    • Travels X,Y,Z: 23.62 x 59 x 27.56
    • Spindle face to table: 3.93-31.5
    • Table: 86.62 x 19.68
    • Spindle: 1500 RPM NMTB 50
    Sharp KMA 3H

  • Bridgeport (3)

    • Travels X,Y: 29.25 x 11.5
    • Table: 48 x 9
    • Spindle: 4200 RPM R8
    Bridgeport Mill

  • Acer Ultima 4VKII

    • Travels X,Y: 29.625 x 14
    • Table:50 x 10
    • Spindle: 3600 RPM NMTB 40

  • Alliant

    • Travels X,Y: 36 x 11.5
    • Table: 58 x 11
    • Spindle: 4200 RPM NMTB 40

  • Hydmech H14A (Automatic)

    • Hydmech H40/60

      Hydmech H40/60

      Cylindrical Grinders

      • Willis LJ22160 CG

        • Max 22” OD x 160” Between Centers
        • Max Weight Between Centers 2200 lbs

        • Steady Rests:

          • (6) Two-Point Ø1.38” – 5.9”
          • (4)  Two-Point Ø5.9” – 10.2”
          • (2) Three-Point Ø8.7” – 13.77”
        • Diamond & Vitrified Wheels (Carbide Coatings & Metals)
        Willis LJ22160 CG

      • Landis 10×24 Type CH

        • Max 10” OD x 24” Between Centers
        • Diamond Wheel (Carbide Coatings)

      • Landis 14×48

        • Max 14” OD x 48” Between Centers
        • Vitrified Wheel (Metals)

      Surface Grinders

      • Norton S-01

        • Max X&Y: 36 x 14
        • Max Height: 7.5

      • Blanchard

        • Max Dia: 42
        • Max Height: 13
        Blanchard Surface Grinder

      • Morrison 1.25 Keyseater

        • 1/16”-1 ¼” Wide
        • Max length 9”
        Morrison 1.25 Keyseater
      • Morrison 3" Keyseater

        Morrison 3″ Keyseater

        • 1/8” – 3”

        • Max length 14”

      Manual

      Head: Sizes:
      FU4-1: 1”-8 UNC 2k 1-12 UNF 2k 1 1/8-7 UNC 2k
      FU45-1: 1 1/16-12 & 1 1/8-12 UNF* 2k 1 ¼-12 & 1 5/16-12 UNF* 2k
      FU4-1: 1”-8 UNC 2k 1-12 UNF 2k 1 1/8-7 UNC 2k
      FU6B-1: 1 1/8-7 & 1 ¼-7 UNC* 1k 1 3/8-12 & 1 1/2-12 UN* 2k 1 ½-8 & 1 5/8-8 UN* 1k 1 ¾-8 & 1 7/8-8 UN* 1k
      FU700: 2-8 & 2 1/8-8 UNJ* 1k 2 1/4-8 & 2 3/8-8 UNJ* 2k
      FU6700: 1 15-16-12 & 2-12 UN* 3k 2 1/2-8 & 2 9/16-8 UNJ* 2k 2 3/4-8 & 2 13/16-8 UN* 1k 3-8 UN 3k
      FU7800: 3 3/8-8 & 3 1/2-8 UNJ* 3k 3 3/8-6 & 3 1/2-6 UNJ* 3k 3 5/8-8 & 3 3/4-8 UN* 2k 4-8 UNJ 3k 4-6 UNJ 3k
      FU11600: 5-8 UNJS 3k

      * Range Rolls

      The machinists at Power Repair Service are trained in using CNC Machining as another method of ensuring efficient, effective repairs.

      • Okuma LB3000 EXII BB 500

        • Turn Dia x Length: 13 ¾” x 17”
        • Schunk ROTA plus 315 12.4” Chuck
        • Riten Face Driver (Type 44)
        Okuma LB3000 EXII
      • Okuma LB45II 3M

        Okuma LB45II w/3M Bed

        • Turn Dia x Length: 20” x 118”
        • Kitagawa B-18 Chuck
        • 2 Riten Face Drivers (Type 64 & Type 66)
        • 2 LNS Stationary Steady Rests (SLU-Z3; .472-5.98)

      • Titan VTL (Fagor T8055i Retrofit)

        • Table Dia: 157 1/2”
        • Max Height (Table to Capto Tool Block): ~9’
        Titan VTL

      • Okuma LU3000 EX

        Okuma LU3000 MY 2SC x 950

        • Turn Dia x Length: 11.9” x 35”?
        • Y Travel: 4.72 (+2.75/-1.96)
        • Schunk ROTA plus 315 12.4” Chuck
        • Neidlein Face Drivers (SB 2 & SB 5)
        • Atling Steady rest (AX2E; .315-4.133 Dia)
        • MP Systems Dual 1000psi/8gpm High Pressure Coolant

      • Okuma Millac 1052V II

        • Nikken CNC401 4th Axis; 15 ¾” Chuck & Tailstock
        • Travels: 41.7 x 120 x 31.5
        • Table: 125.98 x 41.34
        • Spindle face to table: 7.87-39.37
        • Spindle: 6000 RPM BIG-PLUS CAT 50
        • Max Workpiece Weight: 11,000 lbs
        • Lyndex/Mimatic Capto C5 Right Angle Head (Spindle Mount/Single Spindle)
        • Lyndex/Mimatic Capto C5 Right Angle Head (BIG PLUS CAT50 Dual Spindle)
        • MP Systems 1000psi/8gpm High Pressure Coolant
        Okuma Millac 1052V

      • Okuma Millac 761V

        • Nikken CNC260 4th Axis: 12” or 9” Chuck & Tailstock
        • Travels X,Y,Z: 60.63 x 29.92 x 25.98
        • Table: 70.87 x 28.35
        • Spindle face to table: 7.87-33.86
        • Spindle: 6000 RPM BIG-PLUS CAT 50
        • Max Workpiece Weight: 4,400 lbs
        • Lyndex/Mimatic Capto C5 Right Angle Head (BIG PLUS CAT 50 Dual Spindle)
        • MP Systems 1000psi/8gpm High Pressure Coolant

      • Okuma Genos M560

        • Nikken CNC302 4th Axis; 9” or 12” Chuck & Tailstock
        • Travels X,Y,Z: 41.34 x 22.05 x 18.11
        • Table: 51.18 x 22.05
        • Spindle face to table: 2.91-24.02
        • Spindle: 12,000 RPM BIG-PLUS CAT 40
        • Max Workpiece Weight: 1,980 lbs
        • MP Systems 1000psi/8gpm High Pressure Coolant
        Okuma Genos M560

      • Maxcut 4” 3 Axis MHBM-110/B (Fagor M8055i Retrofit)

        • Manual 23” Dia U-Axis w/ 7.22” Travel
        • Travels X,Y,W: 64 x 56 x 24
        • Manual Z w/48” Travel
        • Rotary Table LxW: 49 x 43.3
        • Spindle: 1000 RPM CAT 50
        • Max Workpiece Weight: 6,600 lbs
        • Tailstock
        Maxcut HBM
      • Maxcut HBM

        Maxcut 5” 3+2 Five Axis MHBM-130/B (Fagor M8055 3+2 Retrofit)

        • Manual 30” Dia U-Axis w/10” Travel
        • Travels: 78.74 x 78.74 x 70.87 x 35.43
        • Rotary Table LxW: 70.87 x 63
        • Spindle: 1000 RPM CAT 50
        • Max Workpiece Weight: 22,000 lbs
        • Tailstock

      • Sacem 3+2 Five Axis (Fagor M8055i 3+2 Retrofit)

        • Cogsdill U-Axis w/4” Travel
        • Travels: 20’ x 10’
        • Spindle: 2000 RPM NMTB 50
        • Rotary Table LxW: 98 x 78.5

      LMT Fette Rolling HeadHead: Sizes:
      F3: ½-13 UNC 2k
      5/8-11: UNC 2k
      ¾-10: UNC 2k
      7/8-9: UNC 1k & 2k
      7/16-20: & 12-20 UNF* 2k
      9/16-18: & 5/8-18 UNF* 2k
      3/4-16: UNF 2k
      7/8-14: UNF 2k
      SOLIDWORKS CAD Design Professional (CSWP)

      Top-Grade Industry Software

      • SOLIDWORKS Premium
      • Mastercam (Lathe, Mill2D, Mill3D, Mill-Turn, Multi-axis)
      • DesignX Pro
      • FARO CAM2 Full Edition
      • Camnetics GearTeq
      • Osborn Products ThreadTech

      Reverse Engineering (Laser/Probe)

      • FARO Quantum X.S 2.5m w/8th axis (LLP: FAROBlu xR)
